The Planetarium Wash System uses an innovative double motion of the spray arm. For every revolution of the main arm, the stem of the arm moves in the opposite direction, operating on a second axis. This spiralizing directional wash sprays water evenly in a 360° sweep. The rotation speed is 65rpm, giving the best wash results available.
TYPE

Product Family:Dishwashers
Commercial height:86 cm
Number of place settings:13
Installation:Under counter built-in
Commercial width:60 cm
EAN code:8017709303754
AESTHETICS
Colour:Stainless steel
Front panel colour:Finger friendly stainless steel
Door colour:Finger friendly stainless steel
LED/display colour:White
Buttons colour:Silver (oropal grey)
PROGRAMS / FUNCTIONS








N. of programmes:10+1
Soak:Yes
Express 27':Yes
Mix:Yes
Sterilise:Yes
Self clean:Yes
1/2 load:Yes
Delicate:Yes
Auto:Yes
Crystal & China:Yes
Eco express:Yes
Pots & Pans:Yes
Washing temperatures:38, 45, 50, 55, 65, 70, 75 °F
OPTIONS




Dry Assist option:Yes
Delay timer option:Up to 24 hours
1/2 load FlexiZone option:Yes
Special programs option:Yes
BASKETS



N° baskets:3, FlexiDuo
Basket components colour:Grey
Upper Basket:With 3 foldable racks
Height adjustment of the upper basket:On three levels (5 cm)
Sliding Guides Extra Glide:Yes
Lower Basket:With 4 foldable racks
Largest loadable dish in upper basket:18,0 inches
Lower basket with anti-drip inserts:Yes
Largest loadable dish in lower basket:35,0 inches
Cutlery basket:Yes
Colour Inner Components:Blue
TECHNICAL FEATURES




Display:Delayed start, Programme time indicator, Time to end indication
Door opening system:Yes
Display type:OLED
On/off indicator:Yes
Salt light indicator:Light
Rinse aid indicator:Light
Progress indicator:Yes
End of cycle indicator:On display, with acoustic signal
Washing system:Planetarium
Drying system:Natural condenser drying, with Dry Assist automatic door opening system at the end of the cycle
Motor:Single phase
Third spray arm:Single
Water softener:With electronic setting
Turbidity sensor Aquatest:Yes
Flood protection system:Total Acquastop
Max water hardness:100°fH;58°dH
Internal light:With White led
Tub material:Stainless steel
Filter:Stainless steel
Concealed heating element:Yes
Min. and max plinth height:98 - 168 mm
Hinges:Self balancing with variable hinges
Adjustable feet:7cm, from 860 to 930 mm
PERFORMANCE / ENERGY LABEL

Noise level:44 dB(A) re 1pW
Annual energy consumption:235 KWh/year
Energy Star:Yes
ELECTRICAL CONNECTION
Connected power:1800 W
Current:10 A
Voltage:110-120 V
Type of connection:Single-phase
Frequency (Hz):60 Hz
Power supply cable length:140 "
LOGISTIC INFORMATION
Net weight (kg):115 lbs
Country of origin:IT
Packed width:25 9/16 "
Packaged depth:26 3/8 "
Height (mm) packed:35 1/16 "
Dimensions of the packed product (mm):890X650X670
Maximum stackability:5
Type of packaging:Shrinkwrap
Packaging composition - paper & cardboard (kg):4 lbs
Packaging composition - polystyrene (kg):3 lbs
Other accessories:Salt funel
